Reverse Osmosis Plant (RO)

REVERSE OSMOSIS PLANT

Reverse osmosis system which are designed and manufactured to remove total dissolved solids (TDS) from raw water. A water purification technology that is being used in several industrial & domestic applications. Our unit comprises components like RO membrane cleaners, scale inhibitors, antiscalants, corrosion inhibitors, biocides, de-chlorination, and flocculants. This helps us provide an exceptional product that performs at the highest level yet is and methods.

1.Product Description

The reverse osmosis process can remove chemical contamination as well as microbial or biological contamination, therefore reverse osmosis (RO) systems are utilized for commercial and industrial water purification purposes. The membrane consists of several layers of tightly wound, semi-permeable membrane to remove dissolved contaminants.

2.Functionality

Reverse osmosis is a filtration method for water purification that uses a tightly wound, semi-permeable membrane to remove dissolved contaminants. The application of pressure before the membrane causes the fluid to travel from a region of high solute concentration to a region of low solute concentration to overcome the natural osmotic pressure and redirect dissolved contaminants which result in fine filtration of water. The water flows from the outside layers of the membrane toward the inner layers. The contaminated water gets pushed and exits the membrane on the opposite side of the incoming water as the pure water continues through the layers toward the center of permeate tube.  The separation and removal of micro-contaminants take place as the fluid spirals through the various tightly wound layers of the membrane and into the inner permeate tube collecting all the purified water (permeate) for use.  The rejected water with contaminants (concentrate) flows perpendicular to and out of the backside of the membrane. It can efficiently perform straining or size-reduction of the contaminants of size 0.001 microns in diameter

3.Features
